TD32F

Flanged Thermodynamic Steam Trap

Description

The TD32F is a maintainable medium pressure flanged thermodynamic steam trap which has an integral strainer screen fitted to protect the internals from dirt.
The TD32FLC is designed specifically for low load applications such as steam mains drainage applications.
The TD32FA and TD32FALC are fitted with an anti-air-binding disc to ensure prompt removal of air on start-up.

Standards
This product fully complies with the requirements of the Pressure Equipment Directive (PED).

Certification
This product is available with certification to EN 10204 3.1.
Note: All certification/inspection requirements must be stated at the time of order placement.

Sizes and pipe connections

DN15, DN15LC, DN20, DN20LC, DN25 and DN25LC
Flanged ASME (ANSI) B 16.5 Class 150 and 300, DIN 2501 PN40 and JIS/KS 10, 16 and 20.

Optional extras

Insulating cover (for the DN15 and DN20 only): To prevent the trap being unduly influenced by excessive heat loss such as when subjected to low outside temperatures, wind, rain etc.
TD32F Flanged Thermodynamic Steam Trap

Materials

TD32F Flanged Thermodynamic Steam Trap

No.	Part	Material
1	Body	Stainless steel	ASTM A743 CA-40
2	Cap	Stainless steel	AISI 416
3	Disc	Stainless steel	BS 1449 420 S45
4	Strainer screen	Stainless steel	ASTM A240 316L
Note: The TD32FA and TDFALC are fitted with a 100 mesh stainless steel screen. All other versions have a 0.8 mm perforated screen.
5	Strainer cap	Stainless steel	AISI 416
6	Strainer cap gasket	Stainless steel	BS 1449 304 S16
7	Insulating cover (optional extra for the DN15 and DN20 only)	Aluminium
8	Flanges	Steel	DIN 17243 C22.8 Ws 1.0460
